Functional overview
XMOS 216+ESS9038Pro DAC hardware decoding,DSD512/PCM768KHz 32Bit and MQA.
Dual HDMI audio and video separation output, multi-channel DSD (2.0/5.1CH) playback and DSD Native output.
430 standard dimension, excellent texture with all-aluminum alloy reinforced chassis and shockproof foot pad.
5-inch OLED high-definition touch screen will display general settings, music playback status and touch control.
RTD1619DR SOC with 4K@60Hz, Dolby Vision/HDR10+.
4G DDR4 RAM and 32G eMMC storage;512G SSD for local media storage.
Internal 3.5”/2.5” HDD bay, up to 18T large capacity hard drive (hard drive isn't included).
Dual power supplies, linear power supply and digital power supply.
4K 60Hz, HDR (HDR10/HLG/HDR10+/Dolby Vision), 12Bit, BT.2020 wide color range and YCbCr 4:4:4.
Support DSD (SACD ISO, DSF, DFF), WAV, FLAC, APE lossless audio formats and multi-sampling seamless playback.
High-performance Bluetooth decoding with Qualcomm flagship QCC5125 module, support APTX HD, LDAC audio reception.
6.35 headphone jack, two gain modes switching, the internal headphone amp can drive 16-300 Ω high impedance headphone.
Multi-stage operation amplifier, fully balanced circuit design, XLR balanced and RCA output.
Support asynchronous USB DAC input, monitor-level sound card performance, compatible with Windows, MAC, IOS, Android.
XMOS XU216, MQA full decoding and dual femtosecond active crystal oscillator.
Rigorous circuit design, manufacturing process and selected components.
Based on Linux video decoding and output framework to output image quality with high reproduction.
Support almost all Dolby vision formats and complete processing for stunning image quality.
VS10 engine supports content mapping and colors similar with Dolby vision, the image quality is greatly improved.
Poster wall management system supports automatic intelligent scanning, custom classification and movie info management.
Gigabit wired network and 2.4G+5G dual-band 802.11 AC 2T2R 867Mbps WiFi.
CD-ROM playback and CD Ripping are supported. It can connect with BD (non-encrypted)/CD discs.
New Music Player supports personalized configuration, lyrics matching and track data matching.
support multiple ways of music streaming, such as DLNA,TIDAL Connect,etc
Support music streaming service TIDAL,Qobuz and HIGHRESAUDIO(By mobile control APP)
Support Optical and Coaxial audio input and USB Audio Native, Optical, HDMI digital audio bit-perfect output.
Support multiple network protocols such as NFS, SMB v1/v2/v3,
UPnP and Web DAV.
SMB sharing allow to transmit local media files
stored in Zidoo hard drive to other devices.
