Ultimate HiFi Flagship

UHD3000 is our best product with multiple innovative underlying AV decoding technologies

A ultimate flagship media player combines UHD cinema player with HiFi audio-decoding

Excellent design and craftsmanship, top SOC and 4GB DDR4+32GB eMMC storage

Support Dolby Vision VS10 engine and advanced 4K 12Bit HDR10+/Dolby vision decoding

Support ESS 9068 DAC audio decoding, MQA, and DSD512 hardware decoding

Intoxicating HiFi music experience

Exquisite Craftsmanship and Excellent Quality

Delicate Appearance

Auxiliary heat dissipation aluminum alloy chassis

Aluminum alloy brushed front panel and frosted upper cover

Solid and stable with outstanding texture

Hidden Dual HDD Bays

Hidden dual HDD bays with beautiful design and easy to use

Up to 16TB for each HDD bay

Large LED Display Panel

Various working status indicators

Brightness adjustment and on/off settings

Multiple Gold-plated Ports

Multiple interfaces for various audio-visual equipments

Interfaces with gold-plated supply reliable performance

Independent Dual Power Supplies

UHD3000 digital circuit and analog circuit are equipped with independent power supplies. A group of large toroidal linear power supply provides strong and clean power for audio components and has excellent efficiency to reduce external magnetic field interference. Another group of switching power supply is specially designed for digital circuits. The efficient direct current output improves the quality of audio and video output

ESS9068 Monitor-level DAC Audio Decoding

Zidoo has reached a deep and long-term strategic cooperation with the ESS. UHD3000 is the first one to be equipped with a new generation of ESS 32-bit HyperStream ESS9068 DAC decoder chip. In addition to supporting DSD512 and PCM768@32bit decoding, it also supports three-layer 8 times expanded MQA encoding format hardware decoding. It is the only media player among the field that can support MQA hardware decoding

XMOS + Dual Crystal Oscillators

UHD3000 is equipped with XMOS chip. It works perfectly with Zidoo music player to process ultra-high-sampling master-level audio formats, and can losslessly transfer the original data 1:1 to high-index DAC for hard-decoding output. Two high-precision crystal oscillators (45.1584MHz and 49.152MHz) respectively correspond to 44.1KHz and 48KHz multiplier sampling, which effectively reduce jitter and ensure more accurate audio decoding

High-end HiFi Audio Decoding

UHD3000 has a USB DAC IN port, which greatly expands the audio function. UHD3000 becomes a high-performance audio decoder after connecting to music streamer with SUB output. Sound quality is as good as high-end independent decoding device

Fully Balanced Signal

UHD3000 adopts fully balanced design for the RCA stereo output,XLR output and DAC decoding. It provides better noise immunity. The channel separation degree is improved and the signal quality is more stable and powerful by eliminating the shared loop

Exquisite Craftsmanship Handpicked Components

UHD3000 analog output can present audiophile monitor-level sound quality. The circuit design and materials are handpicked. The main board is made of immersion gold technology, which is equipped with four audiophile operational amplifiers and selected audiophile auxiliary components including NICHCON, WIMA, ELNA etc. Every detail is made with great effort to improve the audio quality

Powerful CPU

UHD3000 is equipped with Realtek RTD1619DR A55 hexa-core 64-bit high-performance processor, which is greater bus processor capacity, response speed and more efficient calculation. The strong decoding performance helps achieving excellent audio-visual playback

Large Memory and Internal Storage

2GB DDR4 large memory comes with fast and smooth playback response, which helps enjoying wonderful movie and music. 32GB eMMC super internal storage supports installing masses of favorite apps and create more possibilities for audio-visual entertainment

Independent HDD Bays and HDMI AV Separate Output

UHD3000 has two independent SATA3.0 HDD bays, each of them supports one hard drive up to 16TB

Dual HDMI ports can support audio and video separate output

4K@60P HDR 12Bit and native 3D immersive audio output

Best choice for audio and video enthusiasts

4K HDR Video Technology

Zidoo aims to give users the ultimate experience of media players with years exploration of leading audio-visual technologies

UHD3000 is equipped with Realtek RTD1619DR hexa-core A55 processor which can easily decode HEVC/H.265 encoded 4K HDR video

Dolby Vision VS10 image quality processing engine is built-in, supports Dolby Vision LLDV processing and 3840 x 2160 60Hz 4K output

Even ordinary film can be processed to get the best picture quality performance

Accurate Frame Rate Switching

UHD3000 supports switching original resolution and frame rate automatically and accurately (23.976,59.94,25,30,50 and 60). The new automatic switching algorithm allows completing the film frame rate switching in advance to ensure smooth and integral film playback

Dolby Vision VS10 Image Quality Engine

UHD3000 integrates Dolby Vision VS10 image engine,which has adopted advanced dynamic metadata processing technology, so that the most suitable brightness could be output for images and scenes of each frame. Shadows are darker while highlights are brighter. Even in the dark and weak-light environment, it could also display the best visual effect. No matter what formats (Dolby Vision, HDR,HLG,SDR etc.) or displaying devices, whether HDR outputting or SDR converting, all could keep color accuracy and bring good experience to customers. Even normal TV could experience Dolby Vision technology

* Brightness range: 0.007nits - 10000nits

Higher Level HDR10+

UHD3000 takes the lead in adding HDR10+ technology, which could not only display peak brightness up to 4000 nits, but also process metadata accurately for each frame. Namely, colors and brightness levels are obtained frame by frame and scene by scene, images could be displayed in details with wide dynamic contrast and richer colors

HDR10+ brightness range: 0.005nits - 4000nits

12Bit Color Depth

UHD3000 new image engine not only supports 10Bit (approximately 1.07 billion colors) decoding and outputs at the resolution of 4K 60Hz, but also supports higher color depth 12 bit (approximately 68 billion colors) . 12 bit has vibrant colors and natural color transition

Wider Color Range

UHD3000 supports BT.2020 wide color range which can display 75% nature colors and closer to what human eyes see, while traditional BT.709 could only display 35% nature colors. It has bright and eye-catching colors, rich and full images, and a better sense of space, three dimension and layering.

Android 9.0

Based on deep development of Android 9.0, the system performance of UHD3000 has greatly improved with better stability and compatibility. Masses of apps could be installed. DRM widevine L1 is also supported

Cool Poster Wall

UHD3000 comes with new movie posters management system in new algorithm

It has concise navigation, personalized category, record viewing and custom collection etc.

It makes movie collection more convenient and fully improves the efficiency of mass movies management

Smooth Blu-ray Seamless Branching Playback

UHD3000 optimizes the video playback engine, which improves the Blu-ray seamless branching playback and says goodbye to stuttering and messy playback issues. BD and UHD Blu-ray menus are played just like enjoying movies in a cinema

Convenient Subtitle Download and Subtitle Setting

UHD3000 supports downloading subtitles and multiple subtitle formats such as PGS, ASS, SSA, SUP, SUB, SRT, etc.; Subtitle font, color, special effects and location can all be customized ; The brightness of graphic subtitles (embedded PGS and external ASS special effects subtitles) can be adjusted, which led the way of the industry ; MKV and Bluray format forced subtitles are also supported

Smart Music Library

Music library can be generated from both network drive and local hard drive. It is so powerful that we could collect and manage masses of audio files and enjoy lossless music

Master-tape Level Audio Decoding

UHD3000 music player supports to play both lossless formats FLAC, WAV, APE, DTS, etc. and master-tape level music formats MQA, DSD512 (SACD ISO/DFF/DSF/DSD). Various sampling formats,CD-ROM playback and CD ripping are also supported ( external CR-ROM is required)

Music Streaming

UHD3000 is perfectly compatible with Roon Ready and Spotify

Support network streaming like high-end music streamer

Roon is an incredibly rich and engaging way to browse and organize your music. It runs on most Mac, Windows, and Linux PCs, or on other products which include Roon Core. Being Roon Ready means that ZIDOO network players transparently discover and connect to Roon without any configuration, and bit-perfect audio is delivered from Roon to your network player. Together, Roon and ZIDOO deliver the power, flexibility, and performance of networked audio, with the easiest setup and highest reliability available.

Learn more about Roon partner programs

Network Sharing Protocol

UHD3000 supports Gigabit network transmission, it could work with NFS, SMB v1/v2/v3, UPnP, FTP network protocols. It will automatically scan all available network drives in the LAN and read data quickly and reliably. NAS, PC and other servers are supported

Zidoo Controller APP

Zidoo Controller APP could control media players seamlessly in LAN. Home Theater and Music Player could be set on cell phone without suspending audio and video playback. Music could be played without turning on displaying device. And media players could be powered on/off without remote control

Smart Control System

Apart from Zidoo Controller cell phone APP, Zidoo also supports HTTP (standard WOL is supported), RS232,HDMI CEC, Bluetooth and IR control methods for smart control system

Learn more about UHD3000 System

UHD3000 HIFI 4K UHD Media Play

Functional overview
